Automobile & IC Engines
Hydraulic Brake System (4 Drum)
Working four-wheel hydraulic drum brake layout with master cylinder, wheel cylinders and pedal.
EXPERIMENTS COVERED
- 01Hydraulic brake circuit
- 02Brake shoe operation
Experiment manual
Theory, procedure and observation tables supplied with every unit.
Install & demo
On-site commissioning and faculty demonstration by our engineers.
Run-tested
Every apparatus is assembled and tested at our Roorkee works.
Pan-India dispatch
Safe crating and delivery to institutions across India and abroad.
