Strength of Materials & Testing
Portal Frame Apparatus
Portal frame with interchangeable supports (fixed, hinged, free) for studying horizontal thrust and deflection.
EXPERIMENTS COVERED
- 01Horizontal thrust in portal frames
- 02Effect of support conditions
Experiment manual
Theory, procedure and observation tables supplied with every unit.
Install & demo
On-site commissioning and faculty demonstration by our engineers.
Run-tested
Every apparatus is assembled and tested at our Roorkee works.
Pan-India dispatch
Safe crating and delivery to institutions across India and abroad.
